DHS80 DH80 Center Joint Hydraulic Wiper Seal DKB DKBI PU Material 80*90*6/8
DHS-80 DH-80 Excavator Center Joint Center Swivel Adjust Wiper Solf DKB DKBI PU Material White Color LBI 80*90*6/8
DHS-80 ,others name DH-80,DSH-80,LBI-80, size 80*90*6/8, is a solf type wiper for valve and pump outside dust guard system, this type wiper using material without iron,in case for suit to the deeper installing situation, mostly see it in the adjust pump and center joint, for the machine models such as
Hitachi Track Adjust:EX300-5,EX270,EX350-5,ZAX330.
Cato Center Joint:HD250-5,HD250-7.
Kobelco Center Joint:SK60-7,SK55C.
Daewoo Center Joint:DH55,DH60-7,DH80-7.
Doosan Center Joint:DX55,DX60.
Hyundai Center Joint:R55,R60-7.
Volvo Center Joint:EC55.
Zhongyou Center Joint:ZCM907.
Yuchai Center Joint:YC85-6,YC65.
Xugong Center Joint:XCMG-80,XCMG-60,XCMG-65,XCMG-70.
Liugong Center Joint:GLC-907,GLC-908C.
Sany Center Joint:SY75C,SY60C-9.
and so on.
Precautions
1. Clean the installation location;
2. Remove the burrs during the installation movement of the seal;
3. Apply lubricant on the seals;
4. Protect the sealing surface from damage;
5. Recheck to confirm that the size of the seal is correct;
6. Use corresponding tools to install the seals that need to be deformed and installed.
| KOBELCO: | SK07-N2 SK55 SK60-1 SK60-2 SK60-3 SK60-5 SK60-6 SK100-1 SK100-2 SK100-3 SK100-5 SK100-6 SK120-1 SK120-2 SK120-3 SK120-5 SK120-6 SK135-7 SK200-1 SK200-2 SK200-3 SK200-5 SK200-6 SK200-6E SK200-7 SK200-8 SK210-6E SK210-7 SK210-8 SK230-6 SK230-6E SK220-3 SK220-6 SK235 SK250-8 SK300-3 SK300-6 SK310-3 SK320-3 SK320-6E SK320-6 SK330-8 SK350 SK350-6 SK350-8 SK400-3 SK09 SK450 |
| SUMITOMO: | SH60 SH75 SH100 SH120-1/2/3/5 SH160 SH200-1/A3 SH210 SH220 SH220A3 SH260 SH300-2 SH350 LS2650FJ-2 LS2800CJ/DJ/EJ/FJ-2 LS2800FJ2 LS2800F2 LS3400EA LS3400FJ LS4300 |
Quick Details
- Size:
-
Standard or custom
- Place of Origin:
-
Fujian, China
- Brand Name:
-
no brand name or TYS
- Model Number:
-
DH-80
- Product name:
-
Dust Wipers Seal
- Type:
-
DH DHS
- Application:
-
Hydraulic system
- Material:
-
PU
- Temperature:
-
-35 to +200 ℃
- Max Speed:
-
≤1 m/s
- Max Pressure:
-
≤1.6 Mpa
- Function:
-
Dust Proof Wiper Seal
- Media:
-
Hydraulic
- Advantage:
-
Good wear resistance
